Norco Torrent DH A1

Frame & fit interfaces

The standards that decide what fits this bike.

Frame material

Aluminum

Wheel size

29/27.5"

Suspension

Full

Rear travel

200 mm

Rear axle spacing

148 mm

Seatpost diameter

31.60 mm

Headset standard

ZS56/28.6 | ZS56/40

Bottom bracket

BSA Threaded, 83mm

Max tire size

2.35" – 2.5"

Stock build

• ForkRockShox BoXXer Select D2, 200mm Travel, 52mm Offset
• Rear ShockRockShox Vivid Air Base, 225x75mm TR
• Front BrakeSRAM Maven
• Rear BrakeSRAM Maven
• Front Brake RotorSRAM Centerline A2, 200mm, 2mm thickness, 6-bolt
• Rear Brake RotorSRAM Centerline A2, 200mm, 2mm thickness, 6-bolt
• Front Brake Padsmetallic pads
• Rear Brake Padsmetallic pads
• Brake LeversSRAM Maven Base
• Bottom BracketPraxis M30, BSA Threaded
• CassetteSRAM PG-720 DH, 7s, 11-25t
• ChainSRAM PC-1110, 11sp
• CranksetPraxis Cadet DH9, 36T, 160mm (S1,S2), 165mm (S3,S4,S5)
• Front WheelNovatec Front Sealed Bearing, 20x110 Boost, 6-bolt, WTB ST Tough TCS 2.0 29in i30 32H
• Rear WheelFormula DHT-148 4SB, 12x148mm Boost, HG, 32h, 6-bolt
• Rear DerailleurSRAM GX DH, Mid Cage
• ShiftersSRAM GX DH
• HandlebarRace Face Chester 35
• StemRace Face Chester Direct Mount, 50mm
• GripsRace Face Chester, 31mm
• HeadsetFSA No. 55/57-1 ZS, Sealed Bearing, Straight 1-1/8", ( ZS56/28.6 | ZS56/40 )
• SaddleSDG Patriot I-Beam
• SeatpostNorco Alloy, 31.6mm, Rigid
• Front TireMaxxis [F] Maxxis Assegai 29x2.5 WT, 3C MaxxGrip, DH, TR
• Rear TireMaxxis Minion DHR II, 3C Maxx Grip DH, 27.5.5x2.4", Folding
