Transition Bikes Smuggler Alloy Deore

Frame & fit interfaces

The standards that decide what fits this bike.

Frame material

Carbon

Wheel size

29"

Suspension

Full

Rear travel

130 mm

Rear axle spacing

148 mm

Seatpost diameter

31.60 mm

Headset standard

Carbon: IS42 (top) / IS52 (bottom); Alloy: 44mm Zero Stack (top) / 56mm Zero Stack (bottom)

Bottom bracket

73mm BSA Threaded

Max tire size

29" x 2.4"

Stock build

• ForkRockShox Psylo Gold RC (140mm)
• StemRace Face Aeffect R (40mm)
• ChainShimano Deore M6100
• GripsODI Elite Flow Lock-On
• SaddleSDG Bel Air 3
• HeadsetFSA No.57E
• CassetteShimano CS-M6100-12
• CranksetShimano Deore M6100 (30t/170mm)
• SeatpostSDG Tellis SM(150mm) MD(170mm) LG/XL(200mm)
• ShiftersShimano Deore M6100 I-SPEC EV
• HandlebarRace Face Chester 35
• Rear TireMaxxis Dissector EXO/TR (2.4)
• Front TireMaxxis Assegai EXO/TR (2.5)
• Rear BrakeShimano Deore BR-M6120
• Rear ShockRockShox Deluxe Select+ (210x50mm)
• Rear WheelNovatec Novatech D791SB/D902SB
• Front BrakeShimano Deore BR-M6120
• Front WheelNovatec Novatech D791SB/D902SB
• Rear DerailleurShimano Deore M6100 SGS 12sp
• Rear Brake RotorShimano RT66 (203/180mm)
• Front Brake RotorShimano RT66 (203/180mm)
