2026 Transition Bikes Spur XT Di2
- Type
- Bike
- Category
- Mountain
- Weight
- 26.8 lbs (12.2 kg)
- MSRP
- $7,499
Frame & fit interfaces
The standards that decide what fits this bike.
- Frame material
- Carbon
- Wheel size
- 29"
- Suspension
- Full
- Rear travel
- 120.00 mm
- Rear axle spacing
- 148.00 mm
- Seatpost diameter
- 31.60 mm
- Headset standard
- IS42 (top) / IS52 (bottom)
- Bottom bracket
- 73mm English Thread
- Max tire size
- 29" x 2.4"
Stock build
- ForkFox Float 34 SL Grip X Factory (130mm)
- StemRace Face Aeffect R (40mm)
- ChainShimano XT CN-8100
- GripsODI Elite Flow Lock-On
- SaddleSDG Bel Air 3 LUX
- HeadsetFSA No.42/48/ACB
- CassetteShimano XT CS-M8200 (10-51t)
- CranksetShimano XT FC-8200 (32t/165mm)
- SeatpostOneUp Dropper Post SM(150mm) MD(180mm) LG/XL(210mm)
- ShiftersShimano XT Di2 SW-M8250-R
- HandlebarRace Face ERA, carbon, 35mm, 40mm rise, 800mm width
- Rear TireMaxxis Forekaster 3C EXO+ (2.4)
- Front TireMaxxis Forekaster 3C EXO+ (2.4)
- Rear BrakeShimano XT M8220 4 Piston
- Rear ShockFox Float SL Factory (190x45mm)
- Rear WheelDT Swiss 350 Spline Ratchet 54
- Front BrakeShimano XT M8220 4 Piston
- Front WheelDT Swiss 350 Spline Ratchet 54
- Rear DerailleurShimano XT Di2 RD-M8250-SGS
- Rear Brake RotorShimano RT86 (180mm)
- Front Brake RotorShimano RT86 (180mm)
