Trek Fuel LX 9.9 X0 AXS Gen 7

Frame & fit interfaces

The standards that decide what fits this bike.

Frame material

Carbon

Wheel size

29"

Suspension

Full

Rear travel

160.00 mm

Rear axle spacing

148.00 mm

Seatpost diameter

34.90 mm

Headset standard

ZS

Bottom bracket

BSA 73mm threaded

Max tire size

29x2.50"

Stock build

• ForkRockShox ZEB Ultimate B1, Linear XL w/ ButterCups, Charger 3.2 RC2 damper, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 170mm travel
• StemRace Face Turbine R, 35mm, 0 degree, 40mm length
• ChainSRAM X0 Eagle, T-Type, 12 speed
• GripsTrek Line Elite, lock-on
• SaddleTrek Aeolus Pro, carbon fiber rails, AirLoom lattice 145mm width
• CassetteSRAM Eagle XS-1295, T-Type, 10-52, 12 speed
• CranksetSRAM X0 Eagle, DUB, 30T steel, T-Type, 55mm chainline, 170mm length
• SeatpostFox Transfer NEO, 175mm travel, wireless, 34.9mm
• ShiftersSRAM AXS pod
• HandlebarRace Face ERA, carbon, 35mm, 40mm rise, 800mm width
• Rear TireMaxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5''
• Front TireMaxxis Assegai, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5''
• Rear BrakeSRAM Maven Silver 4-piston hydraulic disc
• Rear ShockRockShox Vivid Ultimate D1, 205x65mm
• Rear WheelBontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle, 29''
• Front BrakeSRAM Maven Silver 4-piston hydraulic disc
• Front WheelBontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29''
• Bottom BracketSRAM DUB MTB Wide, 73mm, BSA threaded
• Rear DerailleurSRAM X0 Eagle AXS, T-Type
• Rear Brake RotorSRAM HS2, 6-bolt, 180mm
• Front Brake RotorSRAM HS2, 6-bolt, 200mm
